Size：M4-M24
d | M4 | M5 | M6 | M8 | M10 | M10 | M12 | M12 |
P | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.5 | 1.75 | 1.75 |
/ | / | / | 1 | 1 | 1 | 1.5 | 1.5 | |
/ | / | / | / | 1.25 | 1.25 | 1.25 | 1.25 | |
da | 4 | 5 | 6 | 8 | 10 | 10 | 12 | 12 |
4.6 | 5.75 | 6.75 | 8.75 | 10.8 | 10.8 | 13 | 13 | |
dk | 6.5 | 7.5 | 9.5 | 12.5 | 16 | 15 | 18 | 17 |
dw | 5.8 | 6.8 | 8.3 | 11.3 | 15.3 | 14.3 | 17.2 | 16.2 |
e | 7.66 | 8.79 | 11.05 | 14.38 | 18.9 | 17.77 | 21.1 | 20.03 |
7.5 | 8.63 | 10.89 | 14.2 | 18.72 | 17.59 | 20.88 | 19.85 | |
x | 1.4 | 1.6 | 2 | 2.5 | 3 | 3 | / | / |
/ | / | / | 2 | 2 | 2 | / | / | |
/ | / | / | / | 2.5 | 2.5 | / | / | |
G | / | / | / | / | / | / | 6.4 | 6.4 |
/ | / | / | / | / | / | 5.6 | 5.6 | |
/ | / | / | / | / | / | 4.9 | 4.9 | |
h | 8 | 10 | 12 | 15 | 18 | 18 | 22 | 22 |
7.64 | 9.64 | 11.57 | 14.57 | 17.57 | 17.57 | 21.48 | 21.48 | |
7.42 | 9.42 | 11.3 | 14.3 | 17.3 | 17.3 | 21.16 | 21.16 | |
m | 3.2 | 4 | 5 | 6.5 | 8 | 8 | 10 | 10 |
2.9 | 3.7 | 4.7 | 6.14 | 7.64 | 7.64 | 9.64 | 9.64 | |
mw | 2.32 | 2.96 | 3.76 | 4.91 | 6.11 | 6.11 | 7.71 | 7.71 |
SR | 3.25 | 3.75 | 4.75 | 6.25 | 8 | 7.5 | 9 | 8.5 |
S | 7 | 8 | 10 | 13 | 17 | 16 | 19 | 18 |
6.78 | 7.78 | 9.78 | 12.73 | 16.73 | 15.73 | 18.67 | 17.73 | |
6.64 | 7.64 | 9.64 | 12.57 | 16.57 | 15.57 | 18.48 | 17.57 | |
t | 5.26 | 7.21 | 7.1 | 10.65 | 12.65 | 12.65 | 15.65 | 15.65 |
5.74 | 7.79 | 8.29 | 11.35 | 13.35 | 13.35 | 16.35 | 16.35 | |
w | 2 | 2 | 2 | 2 | 2 | 2 | 3 | 3 |
kg | / | / | 4.66 | 11 | 20.1 | / | 28.3 | / |
Advantage:
1. Compared with ordinary metal nuts, the biggest advantage of plastic nuts is that they have good insulation properties and are not conductive.
2. In addition, because of non-metallic manufacturing, there will be no signal interference such as eddy current under the influence of current or other electrical signals.
3. Plastic nuts have better acid and alkali resistance. The best PVDF nut is polypropylene, both of which have strong acid and alkali resistance. Compared with the former two, nylon nuts are resistant to strong acids and alkalis. The performance is relatively poor, so in some strong acid and alkali environments in the electroplating industry, plastic nuts have a wide range of applications.
