Size:M1.6-M10
Surface：ZP
Material:Stainless Steel
d | M1.6 | M2 | M2.5 | M3 | (M3.5) | M4 | M5 | M6 | M8 | M10 |
p | 0.35 | 0.4 | 0.45 | 0.5 | 0.6 | 0.7 | 0.8 | 1 | 1.25 | 1.5 |
a | 0.7 | 0.8 | 0.9 | 1 | 1.2 | 1.4 | 1.6 | 2 | 2.5 | 3 |
b | 15 | 16 | 18 | 19 | 20 | 22 | 25 | 28 | 34 | 40 |
dk | 3.2 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 16 | 20 |
2.9 | 3.7 | 4.7 | 5.7 | 6.64 | 7.64 | 9.64 | 11.57 | 15.57 | 19.48 | |
k | 1.3 | 1.6 | 2 | 2.4 | 2.7 | 3.1 | 3.8 | 4.6 | 6 | 7.5 |
1.42 | 1.72 | 2.12 | 2.52 | 2.82 | 3.25 | 3.95 | 4.75 | 6.15 | 7.68 | |
1.18 | 1.48 | 1.88 | 2.28 | 2.58 | 2.95 | 3.65 | 4.45 | 5.85 | 7.32 | |
x | 0.9 | 1 | 1.1 | 1.25 | 1.5 | 1.75 | 2 | 2.5 | 3.2 | 3.8 |
M1 | 1.8 | 2.5 | 2.7 | 3.1 | 4.2 | 4.6 | 5.3 | 6.8 | 9 | 10.2 |
M2 | 1.8 | 2.4 | 2.6 | 3 | 4 | 4.3 | 5 | 6.7 | 8.8 | 9.9 |
kg | - | - | - | - | - | - | - | - | - | - |
Application field:
Pan head machine screws have high-quality properties such as insulation, non-magnetic, corrosion resistance, beautiful appearance, and never rust. Modified engineering plastics have the strength and impact resistance comparable to metals. The plastic screws we often say are commonly called nylon After 30% glass fiber is added to the screw, its mechanical properties are far better than that of ordinary nylon. The materials used in plastic screws are becoming more and more diversified, the performance is continuously improved, and the application field is becoming wider and wider.
1. Medical equipment industry (insulation, non-magnetic, environmental protection, anti-interference number, making medical machinery and equipment safer to use)
2. Wind power industry (isolation and insulation of chassis circuit PCB boards)
3. Aerospace industry (insulation and anti-interference number on electronic equipment)
4. Office equipment industry (never rust, beautiful and practical)
5. Petrochemical industry (high temperature resistance, chemical resistance, corrosion resistance, extending the service life of equipment)
6. Electronic industry (insulation, anti-interference, light weight)
7. Communication industry (insulation, non-magnetic, safety)
8. Shipbuilding industry (acid resistance, alkali resistance, corrosion resistance, extended service life), etc.
The size is complete to meet the needs of different occasions.
