Size:ST2.2-ST6.3
Surface：ZP
Color:Silvery
Material:Stainless Steel
Head Style:Flat
MOQ:100pcs
Delivery time:5-30 Days
Length:<=120mm, accroding to client request
d | St2.2 | St2.9 | St3.5 | (St3.9) | St4.2 | St4.8 | St5.5 | St6.3 |
P | 0.8 | 1.1 | 1.3 | 1.3 | 1.4 | 1.6 | 1.8 | 1.8 |
a | 0.8 | 1.1 | 1.3 | 1.3 | 1.4 | 1.6 | 1.8 | 1.8 |
dk | 4.3 | 5.5 | 6.8 | 7.5 | 8.1 | 9.5 | 10.8 | 12.4 |
4 | 5.2 | 6.44 | 7.14 | 7.74 | 9.14 | 10.37 | 11.97 | |
k | 1.3 | 1.7 | 2.1 | 2.3 | 2.5 | 3 | 3.4 | 3.8 |
y | 2 | 2.6 | 3.2 | 3.5 | 3.7 | 4.3 | 5 | 6 |
1.6 | 2.1 | 2.5 | 2.7 | 2.8 | 3.2 | 3.6 | 3.6 | |
M1 | 2.5 | 3 | 4.2 | 4.6 | 4.7 | 5.1 | 6.8 | 7.1 |
M2 | 2.4 | 2.8 | 4 | 4.2 | 4.4 | 5 | 6.3 | 7 |
Application:Automotive Industry, Rail Transit, Communications Equipment, Arine Engineering, Aerospace, Machinery Industry, Electronic Manufacturing, Petrochemical Industry, Photovoltaic and Solar Energy Industries and Fields.
