Size:MST2.2-MST8
Surface：ZP
Material:Stainless steel
Head Type:Hex Head
Thread:coarse, fine
Used:building industry machinery
d | St2.2 | St2.9 | St3.5 | (St3.9) | St4.2 | St4.8 | (St5.5) | St6.3 | (ST8) |
P | 0.8 | 1.1 | 1.3 | 1.3 | 1.4 | 1.6 | 1.8 | 1.8 | 2.1 |
a | 0.8 | 1.1 | 1.3 | 1.3 | 1.4 | 1.6 | 1.8 | 1.8 | 2.1 |
e | 0.38 | 5.4 | 5.96 | 7.59 | 7.59 | 8.71 | 8.71 | 10.95 | 14.26 |
k | 1.3 | 1.5 | 2.3 | 2.3 | 2.8 | 3 | 4 | 4.8 | 5.8 |
1.18 | 1.38 | 2.18 | 2.18 | 2.68 | 2.88 | 3.85 | 4.65 | 5.65 | |
1.42 | 1.62 | 2.42 | 2.42 | 2.92 | 3.12 | 4.15 | 4.95 | 5.95 | |
y | 2 | 2.6 | 3.2 | 3.5 | 3.7 | 4.3 | 5 | 6 | 7.5 |
1.6 | 2.1 | 2.5 | 2.7 | 2.8 | 3.2 | 3.6 | 3.6 | 4.2 |
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
