Size:M6-M12
Grade:4.8
Material:Carbon Steel
OEM:Support
MOQ:10000PCS Supply Ability
Usage:Structural Anchorage, Seismic Attachments, Retrofi
Surface:blue White Zinc,Yellow Zinc Plating
SIZE | QTY/CARTON | WEIGHT/MPCS(KG) | SIZE | QTY/CARTON | WEIGHT/MPCS(KG) |
6*8*50 | 1600 | 18.4 | 10*12*150 | 240 | 100.6 |
6*8*60 | 1600 | 18.7 | 10*12*180 | 200 | 120.8 |
6*8*70 | 1400 | 21.9 | 10*12*200 | 180 | 134.3 |
6*8*80 | 1200 | 24.8 | 12*14*80 | 300 | 90.6 |
6*8*90 | 1000 | 28.4 | 12*14*90 | 300 | 82.7 |
6*8*100 | 960 | 31.2 | 12*14*100 | 273 | 91.5 |
6*8*120 | 800 | 37.9 | 12*14*110 | 280 | 101.1 |
6*8*150 | 600 | 47.7 | 12*14*120 | 240 | 110.2 |
8*10*60 | 800 | 32.7 | 12*14*130 | 200 | 118.4 |
8*10*70 | 800 | 31.0 | 12*14*150 | 180 | 138.0 |
8*10*80 | 680 | 35.5 | 12*14*180 | 160 | 167.2 |
8*10*100 | 600 | 44.3 | 12*14*200 | 120 | 186.6 |
8*10*110 | 500 | 48.8 | 12*16*80 | 300 | 82.2 |
8*10*120 | 480 | 53.7 | 12*16*90 | 280 | 93.6 |
8*10*130 | 440 | 58.6 | 12*16*100 | 240 | 103.5 |
8*10*150 | 400 | 67.8 | 12*16*110 | 220 | 114.8 |
10*12*60 | 500 | 39.1 | 12*16*120 | 200 | 125.4 |
10*12*70 | 500 | 46.1 | 12*16*130 | 200 | 136.7 |
10*12*80 | 480 | 52.4 | 12*16*150 | 160 | 157.2 |
10*12*100 | 380 | 65.9 | 12*16*180 | 120 | 190.1 |
10*12*120 | 320 | 79.8 | 12*16*200 | 118 | 211.3 |
10*12*130 | 280 | 87.0 |
Used in masonry and concrete.
Rounded end for easy installation.
Dog point impact section to prevent thread damage during installation.
1. Anti-natural corrosion, anti-corrosion can reach 10 years when used in outdoor walls.
2. High-quality raw materials, advanced equipment, and exquisite craftsmanship make the processed products smooth and free of burrs. The gap between the buckle of the bolt and the nut has reached the level of non-slippery.
3. Widely used in security nets, security windows, construction sites, large machinery and other fields.
Application:
1. Drill.
2. Clean the hole.
3. Anchor ojbects aligned holes, insert the anchor bolt.
4. Rotating the nut clockwise.
5. Do not stop until you cannot turn screw any more.
By default, our company uses the ordinary packaging, that is corrugated carton and white box. there are no any other words except the specifications and quantities on the packaging. if you have special need, we can customize the packaging mark for you. and we can provide fumigated pallets.
